Protek-13 Spray-On Insulation Protectant
CSI: 09 96 13
Protek-13 is a protective coating for new or previously installed applications of fibrous insulations and coatings like K-13 or fireproofing. Composed of a water-based vinyl-acrylic emulsion containing interlacing fibers, Protek-13 is spray-applied to fibrous insulation resulting in a uniform surface finish that effectively guards against physical damage and airborne contaminants without significantly compromising the acoustic performance of materials underneath.
Spray-On Protection
Protek-13 is ideal for interior and covered exterior applications where high-traffic and industrial conditions require additional protection from abrasion and airborne contaminants such as dust, dirt, or fumes. Though appropriate for humid environments such as parking garages, Protek-13 should not be specified in areas where the coating is regularly exposed to excessive moisture such as rain or pressure washing.
Protek-13 is Class 1, Class A Fire-Rated and available in standard white and custom colors to meet design requirements.
Protection from Physical Damage
High-traffic areas are often vulnerable to physical damage from personnel, machinery, birds, and other sources. Protek-13 resists abrasion and prevents “picking away” of the fibers, extending the life of your fibrous insulation.
Additionally, Protek-13 provides superior hiding characteristics making it a great solution for previously installed applications of K-13
Protection from Airborne Contaminants
Dust, dirt, grease, and fumes are present in almost every industrial environment. The firmer, more uniform surface of Protek-13 significantly reduces the accumulation of these airborne contaminants. For clean-up, Protek-13 can easily be swept with a broom, blown clean with compressed air, or lightly washed with water (no scrubbing).
SoUND CONTROL
Protek-13 provides a protective coating for K-13 Thermal and Acoustical insulation without significantly affecting the acoustical performance of the material underneath.
The following test was conducted by spraying two separate thicknesses of Protek-13 over 1.75″ of K-13 Thermal and Acoustical insulation. System 1 was applied in a standard coating, covering 96-98% of the K-13 underneath. System 2 was a heavy-build covering 99-100% of the underlying K-13.
ASTM C 423 - Sound Absorption (NRC)
Standard Protek-13 over K-13 on Solid Backing
Inches 125 Hz 250 Hz 500 Hz 1,000 Hz 2,000 Hz 4,000 Hz NRC
1.5” 0.3 0.6 1.09 1.09 1.02 0.95 0.95
2.25” 0.4 0.73 1.04 1.02 1.02 0.97 0.8
Heavy Protek-13 over K-13 on Solid Backing
Inches 125 Hz 250 Hz 500 Hz 1,000 Hz 2,000 Hz 4,000 Hz NRC
1.75” 0.32 0.53 0.69 0.56 0.36 0.29 0.55
Standard Protek-13 over K-13 on 1.5” Metal Deck
Inches 125 Hz 250 Hz 500 Hz 1,000 Hz 2,000 Hz 4,000 Hz NRC
1.75” 1.02 0.96 0.96 0.71 0.47 0.35 0.8
Heavy Protek-13 over K-13 on 1.5” Metal Deck
Inches 125 Hz 250 Hz 500 Hz 1,000 Hz 2,000 Hz 4,000 Hz NRC
3” 0.95 0.87 0.9 0.64 0.47 0.35 0.7
CUSTOM COLORS AVAILABLE
Protek-13 is available in standard white as well as specially-matched custom colors.
Note: Color selection will affect the final price.
Protek-13 Standard Color Chart
Note: Color selection will affect the final price.
SUSTAINABILITY
Protek-13 is a sustainable protective coating designed to prolong the durability and useful life of fibrous insulations and materials in areas with heavy traffic or industrial exposure. It is formulated with pre-consumer recycled content, supporting environmental stewardship. The coating’s highly reflective surface, particularly white, can significantly enhance lighting efficiency.
Protek-13 is a low-emitting building material with a VOC content level below one g/L. It complies with stringent South Coast Air Quality Management District (SCAQMD) rules 1113 and 1168. Moreover, its formulation excludes silica dust, asbestos, mineral or glass fibers, and PCBs, promoting safer application and usage.
TECHNICAL DATA
ASTM Standards Compliance
ASTM C 423 – Sound Absorption (NRC)
ASTM E 84 – Surface Burning Characteristics
ASTM E 736 – Bond Strength
ASTM E 84 – Surface Burning Characteristics
Protek-13 has a Class 1, Class A fire rating per ASTM E 84/ UL 723/ NFPA 255/ UBC 42
- Flame Spread – 5
- Smoke Developed – 25
ASTM E 736 – Cohesion/Adhesion – Bond Strength
PROTEK-13 APPLIED OVER K-13
Bond Strength: >300 psf
